Electric Chain Hoists - Porta Hoist

Electric Chain Hoists – Porta Hoist

Portable Electric Chain Hoists. A lightweight, compact, portable lifting solution. They conveniently fit in their own durable travel case, making them the ideal portable solution for safe lifting, lowering and handling loads up to 500 kg.

Using only 240V single-phase power, these are suitable to plug into a general power outlet. All models include an overload-limited clutch plus upper and lower limit switches for extra safety.

As standard they are fitted with ergonomic, low voltage IP65 pendant with 2 speed control plus emergency stop. The low speed is variable and the high speed is fixed.

Supplied standard with 6m height of lift, a chain bucket, 5m pendant cable length and 3m power cord. A powered girder trolley is available for these units.

Additional Information

All Porta Hoists are manufactured to comply with AS1418.2
All models suitable for 240 volt, 50 Hz single phase power supply
Duty cycle rated at 30% ED with 180 starts per hour
18 volt DC low voltage control for safe operation
IP65 pendant control, dual speeds with variable speed slow control for raise and lower
Overload protection clutch prevents damage caused by overloading
6 metre height of lift, 5 metre pendant control, and 3 metre power supply cable
Upper and lower electrical limit switches
Supplied with durable travel case

Product Variations

Description	Product Code
Porta Hoist Single Phase 240V Two Speed 125kg capacity	LPPH125	Add to Quote Request
Porta Hoist Single Phase 240V Two Speed 250kg capacity	LPPH240	Add to Quote Request
Porta Hoist Single Phase 240V Two Speed 500kg capacity	LPPH500	Add to Quote Request
Porta Hoist Girder Trolley Single Phase 240V Single Speed 14m/min 500kg capacity	LPPHT050	Add to Quote Request
