Drum Lifting Trolley Palletising

+ Add to Quote Request

Australian made device, designed for high volume handling of drums on/off pallets. The heavy-duty hydraulic lift system is via foot pedal. Device features a self levelling action to allow safe handling of open top drums. The hydraulic cylinder includes a precision needle-valve for smooth control when lowering the drum. The unique “V” shaped base frame allows the operator to corner-approach the pallets. Very safe and simple to use device. It has a capacity of 350 kg and can palletise and depalletise most steel and plastic 205L drums. The automatic ‘beak’ rim-grip engagement mechanism lifts the drums to a max height of 500 mm (floor to underside of drum).

  • Height 1470 mm
  • Width 1000 mm
  • Length 1000 mm
  • Wheels 150 mm diameter
  • Capacity 350 kg

Product Variations

Image Description Product Code Price (excl. GST)

Palletising Drum Lifter
Suitable for Steel and Plastic drums
