E-Z Climber – Stair Climbing Load Carrier

+ Add to Quote Request

The E-Z Climber is an innovative Stair Climbing Load Carrier that transports all types of objects up and down stairs and across uneven slopes.

As an indispensable piece of equipment, it moves heavy loads simply and safely. Designed to carry delicate or heavy objects, the E-Z Climber stair climber is available in three models – Standard, Horizontal and Vertical (all dependent on the movement of the platform). It provides a whole range of benefits to many manual handling tasks and is incredibly easy to use. It is cost-effective as it reduces the number of operators required to complete a task and it ensures staff avoid physical exertion, fatigue or other associated handling injuries.

Ideal for loads like pianos, artworks, heavy safes, vending machines, photocopiers and refrigerators. It moves up and down stairs, ramps or slides with ease.

Clear

Additional Information

E-Z Climber reduces risks and increases production!

Thanks to its compact size, elevation and unique roller system, the E-Z Climber Stair Climbing Load Carrier is simple to use, multipurpose and completely manoeuvrable. The unit can rotate and navigate small spaces with ease, with cost and time savings. An electromagnetic brake and electronic joystick also assists the user, providing them with more control to achieve safe operation and precise movements.

Easy operation moving up and down stairs, ramps and inclines.

E-Z Climber - Operation of Tracks

E-Z Climber - Lifting

Track Operation

E-Z Climbers are equipped with two independent tracks that offer variable speeds (fast and slow). This helps the device overcome slopes, stairs or other obstacles. Operation is controlled by the joystick that helps steer the unit across differing terrains.

Lifting

The E-Z Climber can lift up to 70 cm from the ground, transforming itself into a cart that can be pushed to overcome obstacles and climbing up and down stairways. This action helps the device turn around in confined spaces.

E-Z Climber - Lengthways Translation

E-Z Climber - Rotation on Rollers

Lengthwise Translation

The E-Z Climber can lift up to 70 cm from the ground, transforming itself into a cart that can be pushed to overcome obstacles and climbing up and down stairways. This action helps the device turn around in confined spaces.

Rollers and Rotation

As part of the E-Z Climbers balancing arrangement, the unit can rotate its lift foot rollers to allow a trajectory adjustment. This is an ideal feature that is especially useful when navigating stairs as it increases safety during operation.

Three models of E-Z Climber for you to choose!
E-Z Climber Standard Stair Climber

Ideal for transporting a range of objects. The device features a 600 kg load capacity, protected handle and easily accessible functions. It navigates commands via its proportional manipulator, with a reclining helm and hydraulic lift (equipped with rollers). The E-Z Climber Standard has independent tracks for curvature and a gradient of 45%.

Specifications:

  • Length – 1280 mm
  • Width – 540 mm
  • Platform Length – 1205 mm
  • Platform Width – 430 mm
  • Forward Max Extension – 500 mm
  • Minimum Platform Height – 325 mm
  • Maximum Platform Height – 700 mm
  • Weight – 300 kg
  • Load Capacity – 600 kg
  • Drive Speed – 12,5 m/min
  • Power w – 2 x 700
  • Batteries 2 x 12 VDC – 65 Ah
  • Capability of one charge ( ≈ ) – 50 floors
E-Z Climber Standard

E-Z Climber Standard

E-Z Climber Horizontal Stair Climber

This particular model is perfect for transporting objects of horizontal dimensions and that need to maintain a horizontal position (like printers, photocopiers, pianos). It facilitates anchoring, storage and the loading processes of certain types of materials. The E-Z Climber Horizontal prevents fluid loss as it features a movable platform to ensures a product is kept in a correct position.

Specifications:

  • Length – 1280 mm
  • Width – 540 mm
  • Platform Length – 1205 mm
  • Platform Width – 430 mm
  • Forward Max Extension – 500 mm
  • Minimum Platform Height – 370 mm
  • Maximum Platform Height – 745 mm
  • Weight – 340 kg
  • Load Capacity – 600 kg
  • Drive Speed – 12,5 m/min
  • Power w – 2 x 700
  • Batteries 2 x 12 VDC – 65 Ah
  • Capability of one charge ( ≈ ) – 50 floors
E-Z Climber Horizontal

E-Z Climber Horizontal



E-Z Climber Vertical Stair Climber

This particular model is used to transport all types of bulky objects that need to maintain a vertical development. It easily anchors an item in a vertical position and carries it an inclination. Thanks to stabilisers, all the loads are transported securely and safely. The E-Z Climber Vertical Stair Climber features similar options as the Standard, but with a platform that anchors products into a vertical position.

Specifications:

  • Length – 1280 mm
  • Width – 540 mm
  • Platform Length – 1205 mm
  • Platform Width – 430 mm
  • Forward Max Extension – 500 mm
  • Minimum Platform Height – 405 mm
  • Maximum Platform Height – 780 mm
  • Weight – 345 kg
  • Load Capacity – 600 kg
  • Drive Speed – 12,5 m/min
  • Power w – 2 x 700
  • Batteries 2 x 12 VDC – 65 Ah
  • Capability of one charge ( ≈ ) – 50 floors
E-Z Climber Vertical

E-Z Climber Vertical

How to work the operational controls…

The E-Z Climbers integrated control system offers a user complete control and flexibility. The stair climber will respond to instruction, targeting a number of directions and commands simply and safely. In transport mode, the user always has control.

PianoPlan Operation Controls

Proportional driving control (manipulator) Emergency stop button Red led roller lifting system Key selector Green LED  6 Control button for the roller lifting system Hour counter 8 Drive speed selector Pilot light for driving speed and alarm 10 Pilot light for batteries charger 11 Drive control light 12 Control button for platform movement 13 Control button for roller lifting system 14 Control button for platform inclination (not available on E-Z Climber Standard).

Require something else?

If the E-Z Climber isn’t what you’re after, then feel free to continue to browse our impressive Stair Climber range!

Product Variations

Image Description Product Code Price (excl. GST)

E-Z Climber Stair Climbing Load Carrier [standard]

EZC600

E-Z Climber Stair Climbing Load Carrier [horizontal]

EZC600H

E-Z Climber Stair Climbing Load Carrier [vertical]

EZC600V
